Specifications:

• RMS Power Handling: 750 Watts

• Max Power Handling: 1500 Watts

• Push Terminal Wire Gauge: 8 Ga

• Nominal Impedance: Dual 2 Ohm

• Voice Coil Diameter: 3"

• Frequency Response: 10 Hz ~ 500 Hz

• Sensitivity: 82.4 dB

• Magnet Weight: 240 Oz (Entire Assembly)

• Displacement Volume: 5.2 L / 0.19 cu.ft

Thiele & Small Parameters

• Free Air Resonance (Fs): 29.9 Hz

• Resistance (Re): 1.9 Ohm

• Mechanical Factor (Qms): 6.55

• Electrical Factor (Qes): 0.61

• Total Factor (Qts): 0.55

• Equivalent Volume (Vas): 34.9 L

• Compliance (Cms): 90 um/N

• BL Factor (BL): 95.5

• Moving Mass (Mms): 300.8 g

• Excursion Max (Xmax): 18 mm

Measurements:

• Overall Diameter: 12.80" / 325 mm

• Mounting Diameter: 11.22" / 285 mm

• Bolt Pattern Diameter: 11.93" / 303 mm

• Overall Depth: 8.82" / 224 mm

• Mounting Depth: 7.32" / 186 mm

Enclosure Suggestions:

Sealed:

• 25 L / .706 cu.ft

• Qtc: 0.55

Ported Compact:

• 46 L / 1.63 cu.ft

• P.A.: 4"

• Length :  10.58" / 26.9 cm

• FB: 38 Hz

Ported:

• 75 L / 2.63 cu.ft

• Port Area: 2x3"

• Length: 10.64" / 27.2 cm

• FB: 32 Hz
